Pioneer Water TanksSKU OC374000490676
Aqualine Corrugated Steel Water Tank | 55,000 Gallon | Dome Roof
Price on request
Priced per project. Your quote covers the tank, freight to your site and the estimated lead time.
Images may be inaccurate. See specs below to ensure accuracy.
Specifications
Size
Build
Ordering
- Brand
- Pioneer Water Tanks
- SKU
- OC374000490676
- Made to order
- Yes
Request a quote
- Tell us about the projectUse the form, or call (863) 261-8388.
- A tank specialist checks the detailsSite, foundation, fittings and delivery access.
- You get a written quoteThe tank, freight to your ZIP and the estimated lead time.
Quoting Aqualine Corrugated Steel Water Tank | 55,000 Gallon | Dome Roof
All specifications
Size
Build
Ordering
- Brand
- Pioneer Water Tanks
- SKU
- OC374000490676
- Made to order
- Yes
Description
The Aqualine 3602D is a corrugated galvanized steel water tank with a dome roof, offering a nominal capacity of 55,249 US gallons in a 36' diameter footprint. Aqualine is the value line from the Pioneer Water Tanks family, proudly manufactured in Texas from American steel for dependable rural, agricultural, and commercial water storage.
Aqualine HD tanks are built from .040 in (20 gauge) corrugated G90 galvanized steel wall panels with galvanized trusses and Grade 5 bolts. The dome roof is the most economical option and excellent where height restrictions apply.
Water is stored inside the Bartliner® DST, a woven polyethylene food grade liner that is BPA free and phthalate free, NSF/ANSI 61 certified for use in contact with drinking water.
Every tank includes a 2 in outlet and ball valve, 6 in overflow assembly with down pipe and flapper, 24 in access hatch, leaf filter basket, and liner underlayment. Optional accessories include ladders, galvanized flanges, level indicators, anti vortex assemblies, and FDC connections. Pricing is provided by custom quote based on your site, fittings, and freight.
Applications
Configured at quote time for your application and fittings. Common applications include:
- Rainwater collection: affordable large capacity storage for roof catchment systems
- Livestock and agriculture: dependable stock and irrigation water in three roof styles
- Rural domestic storage: household reserve with an NSF/ANSI 61 certified liner
- Height restricted sites: dome and low profile roof styles keep overall height down
Ready to size your tank? Every Aqualine quote is configured for your site, fittings, and freight.
Request a QuoteOr call 1-863-261-8388 for availability and pricing.
More details
Specifications
| Model | Aqualine 3602D |
| Series | HD, Dome Roof |
| Nominal Capacity | 55,249 US gallons |
| Tank Diameter | 36' |
| Wall Height | 7' 4" |
| Tank Height | 7' 6" |
| Approx. Tank Weight | 4,895 lb |
| Wall Material | .040 in (20 gauge) corrugated G90 galvanized steel |
| Roof | Dome roof, 26 gauge corrugated Galvalume panels |
| Bolts | Grade 5 |
| Trusses | Galvanized |
| Liner | Bartliner® DST woven polyethylene, food grade, BPA free, phthalate free |
| Standard Accessories | 2 in outlet and ball valve, 6 in overflow with down pipe and flapper, 24 in access hatch, leaf filter basket, liner underlayment |
| Compacted Base Pad Diameter | 42' |
| Concrete Pad Diameter | 38' |
| Ships From | Round Mountain, TX (FOB) |
Pack weight and crate dimensions are provided with your quote.
