1500 Gallon Peabody ProChem PLUS DCS Dual Containment Base Tank Set

The 1500 gallon Peabody ProChem PLUS DCS Dual Containment Base Tank Set is the base set for a ProChem PLUS dual containment system: the primary tank and its containment shell, supplied with the parts that make the pair work together. Centering posts, two secondary vents, an overflow, a containment drain and lifting lugs are all included.

Measuring 72" diameter x 118" high, this ProChem PLUS DCS Dual Containment Base Tank Set holds 1500 gallons.

MATERIAL OPTIONS

• Linear Polyethylene (LPE) 1.5 SG — Part No.: 293-35855 (NSF/ANSI 61 certified resin)
• Linear Polyethylene (LPE) 1.9 SG — Part No.: 293-35856 (NSF/ANSI 61 certified resin)

Value-Pak packages are offered with the natural-color Linear Polyethylene (LPE) 1.5 SG and 1.9 SG tanks.

WHAT EACH PACKAGE INCLUDES

Silver — Part No.: 293-35870

• Welded double-wall tank with interstitial supports and a vented twist lid
• Top discharge with dip tube
• Fill connection and a 2" electronic level connection
• Mushroom vents on the containment tank
• Welded primary-to-secondary overflow pipe assembly
• Secondary containment drain connection, plugged
• PVC/EPDM bulkhead fittings, 2" standard size
• Suction tube with a PVC/EPDM ball foot valve and internal pipe support
• Hydrotested before shipping
• CAD submittal drawings
• Shipping prep to protect the tank in transit

Gold — Part No.: 293-35871

Everything in Silver except the PVC/EPDM bulkhead fittings, plus:

• Welded polyethylene couplings in place of the bulkhead fittings, threaded or flanged, 2" standard size
• PVC/EPDM truck fill connection mounted on the tank sidewall at 42 in high, with a PVC/EPDM ball valve, check valve, PVC drop line, polypropylene quick coupler, cap and lanyard
• Lifting lugs
• RF-capacitance leak detection sensor in the secondary tank, in a 1" FNPT coupling, ready for a remote controller or leak alarm (sold separately)

Platinum — Part No.: 293-35872

Everything in Gold except the top discharge with dip tube, plus:

• Mini inverse level gauge
• Bottom sidewall dual containment drain connection with a side access box and visual inspection port (flooded suction with a 1" or 2" stainless steel flex hose) in place of the top discharge
• OSHA-compliant, corrosion-resistant fiberglass access ladder with its mounting hardware

FEATURES

• Base tank set: primary tank plus its containment shell
• Includes centering posts, two secondary vents, overflow, containment drain and lifting lugs
• Choice of a 16 inch lid, a 22 inch twist-on manway or a 24 inch bolted lid
• Available in 1.5 and 1.9 specific gravity linear polyethylene

Chemical suitability depends on your specific chemical, its concentration and its temperature, and is the buyer's responsibility to verify before ordering. The specific gravity rating states the heaviest liquid the wall is designed to hold — a 1.5 wall up to about 12.5 lb per gallon, a 1.9 wall up to about 16 lb per gallon.

These are vented, atmospheric storage tanks. Not for pressurized or vacuum service.

CHEMICAL COMPATIBILITY RESOURCES

• Peabody Chemical Resistance Chart (PDF)
• Polyethylene Chemical Resistance Chart (PDF)
• Polypropylene Chemical Resistance Chart (PDF)
• Chemical Compatibility Tool

Compatibility data is published by resin and chemical suppliers as general guidance only. Contact us with your chemical, concentration and temperature before you order.

KEY SPECIFICATIONS

• Product Type: ProChem PLUS DCS Dual Containment Base Tank Set
• Tank Shape: Cylindrical
• Pressurized Use: No
• Capacity: 1500 Gallons
• Dimensions: 72" diameter x 118" high
• Material: Linear Polyethylene (LPE) 1.5 SG (293-35855)
• Material: Linear Polyethylene (LPE) 1.9 SG (293-35856)
• Value-Pak Silver: 293-35870
• Value-Pak Gold: 293-35871
• Value-Pak Platinum: 293-35872
• Color: Natural
• ANSI/NSF 61 Approved Resin: Yes
• Manufacturer: Peabody Engineering
• Manufacturer Part Number: 293-35855 / 293-35856

SHIPPING INFORMATION

• Freight Class: 250
• Locations: Liberty, South Carolina
• Zip Codes: 29657

WARRANTY TERMS

Peabody Engineering warrants this product against defects in material and workmanship for 36 months from the date of shipment, when it is installed, used and maintained as intended. Chemical compatibility, service temperature and liquid specific gravity are the buyer's responsibility: damage from an incompatible chemical, from service above the rated temperature, or from a liquid heavier than the wall rating is not covered.

Custom and Made to Order products are not returnable
