Peabody EngineeringSKU OC372025420651
400 Gallon Peabody ProChem Open Top Process Chemical Tank (47 in Dia)
Images may be inaccurate. See specs below to ensure accuracy.
Specifications
Size
- Capacity
- 400 gal
- Length
- 54″
- Width
- 54″
- Height
- 61″
Build
- Specific Gravity
- 1.5 (LPE)
- Specific Gravity
- 1.9 (LPE)
Ordering
- Brand
- Peabody Engineering
- SKU
- OC372025420651
- Made to order
- Yes
- Estimated lead time
- 3-4 weeks
Key specs
- Capacity
- 400 gal
- Length
- 54″
- Width
- 54″
- Height
- 61″
- Estimated lead time: 3-4 weeksMade to order, then ships
- Freight to your ZIPEstimate it below or at checkout
All specifications
Size
- Capacity
- 400 gal
- Length
- 54″
- Width
- 54″
- Height
- 61″
Build
- Specific Gravity
- 1.5 (LPE)
- Specific Gravity
- 1.9 (LPE)
Ordering
- Brand
- Peabody Engineering
- SKU
- OC372025420651
- Made to order
- Yes
- Estimated lead time
- 3-4 weeks
Description
The 400 gallon Peabody ProChem Open Top Process Chemical Tank is a cylindrical day tank with its lid included, for chemical process work where the operator needs to get inside the tank. Molded-in calibration on a flat sidewall panel reads the level in gallons and litres.
Measuring 47" diameter x 59" high, this ProChem Open Top Process Chemical Tank holds 400 gallons and opens through a 52 in lid.
MATERIAL OPTIONS
- Linear Polyethylene (LPE) 1.5 SG — Part No.: 01-36292 (NSF/ANSI 61 certified resin)
- Linear Polyethylene (LPE) 1.9 SG — Part No.: 01-36293 (NSF/ANSI 61 certified resin)
- Cross-Linked Polyethylene (XLPE) — Part No.: 01-36294 (NSF/ANSI 61 certified resin)
- Polypropylene (PP) — Part No.: 01-36443
- PVDF — Part No.: 01-36444
FEATURES
- Lid included; overall height is measured from the floor to the top of the lid
- Flat calibrated sidewall panel reads in gallons and litres
- LPE certified to NSF/ANSI/CAN 61 in all sizes; XLPE from 55 to 500 gallons
- Natural is standard, with Gemini blue and black available, plus polypropylene and polyvinylidene fluoride (PVDF) to order
- The listed diameter excludes the top rim flange
MATERIAL SELECTION GUIDANCE
Linear polyethylene (LPE) is typically selected for general chemical and water storage; cross-linked polyethylene (XLPE) where greater impact and stress-crack resistance is preferred; polypropylene (PP) and polyvinylidene fluoride (PVDF) for resin-specific chemistries. Choose based on chemical compatibility first: suitability depends on your specific chemical, its concentration and its temperature, and is the buyer's responsibility to verify before ordering. The specific gravity rating states the heaviest liquid the wall is designed to hold — a 1.5 wall up to about 12.5 lb per gallon, a 1.9 wall up to about 16 lb per gallon.
These are vented, atmospheric storage tanks. Not for pressurized or vacuum service.
CHEMICAL COMPATIBILITY RESOURCES
- Peabody Chemical Resistance Chart (PDF)
- Polyethylene Chemical Resistance Chart (PDF)
- Polypropylene Chemical Resistance Chart (PDF)
- Chemical Compatibility Tool
Compatibility data is published by resin and chemical suppliers as general guidance only. Contact us with your chemical, concentration and temperature before you order.
More details
TECHNICAL DRAWINGS & GUIDES
Technical Drawing: View Technical Drawing
KEY SPECIFICATIONS
- Product Type: ProChem Open Top Process Chemical Tank
- Tank Shape: Cylindrical
- Pressurized Use: No
- Capacity: 400 Gallons
- Dimensions: 47" diameter x 59" high
- Material: Linear Polyethylene (LPE) 1.5 SG (01-36292)
- Material: Linear Polyethylene (LPE) 1.9 SG (01-36293)
- Material: Cross-Linked Polyethylene (XLPE) (01-36294)
- Material: Polypropylene (PP) (01-36443)
- Material: PVDF (01-36444)
- Color: Natural
- ANSI/NSF 61 Approved Resin: No
- Manufacturer: Peabody Engineering
- Manufacturer Part Number: 01-36292 / 01-36293 / 01-36294 / 01-36443 / 01-36444
SHIPPING INFORMATION
- Freight Class: 250
- Locations: Liberty, South Carolina
- Zip Codes: 29657
WARRANTY TERMS
Peabody Engineering warrants this product against defects in material and workmanship for 36 months from the date of shipment, when it is installed, used and maintained as intended. Chemical compatibility, service temperature and liquid specific gravity are the buyer's responsibility: damage from an incompatible chemical, from service above the rated temperature, or from a liquid heavier than the wall rating is not covered.
Custom and Made to Order products are not returnable
