30 Gallon Peabody ProChem Solid Top Process Chemical Tank

$267.99

30 Gallon Peabody ProChem Solid Top Process Chemical Tank

! Images may be inaccurate. See specs below to ensure accuracy.

Specifications

Size

Capacity
30 gal
Length
20″
Width
20″
Height
38.17″

Build

Specific Gravity
1.5 (LPE)
Specific Gravity
1.9 (LPE)

Ordering

Brand
Peabody Engineering
SKU
OC372025960651
Made to order
Yes
Estimated lead time
3-4 weeks

Key specs

Capacity
30 gal
Length
20″
Width
20″
Height
38.17″
All specifications
  • Estimated lead time: 3-4 weeksMade to order, then ships
  • Freight to your ZIPEstimate it below or at checkout
Add to your order (optional)
Adding to cart… category.add_cart_announcement
Questions about sizing or delivery? Call (863) 261-8388Mon–Fri, 8am–5pm EST

All specifications

Size

Capacity
30 gal
Length
20″
Width
20″
Height
38.17″

Build

Specific Gravity
1.5 (LPE)
Specific Gravity
1.9 (LPE)

Ordering

Brand
Peabody Engineering
SKU
OC372025960651
Made to order
Yes
Estimated lead time
3-4 weeks

Description

The 30 gallon Peabody ProChem Solid Top Process Chemical Tank is the closed-cover version of Peabody's cylindrical process tank, fitted with a threaded twist lid for installations where a removable cover is not wanted. Everything else, from the calibration to the resin choice, matches the open top line.

Measuring 18" diameter x 36.17" high, this ProChem Solid Top Process Chemical Tank holds 30 gallons and opens through a 8 in lid.

MATERIAL OPTIONS

  • Linear Polyethylene (LPE) 1.5 SG — Part No.: 01-30356 (NSF/ANSI 61 certified resin)
  • Linear Polyethylene (LPE) 1.9 SG — Part No.: 01-34627 (NSF/ANSI 61 certified resin)
  • Cross-Linked Polyethylene (XLPE) — Part No.: 01-30412
  • Polypropylene (PP) — Part No.: 01-30367
  • PVDF — Part No.: 01-30378

FEATURES

  • Solid molded top with a threaded twist lid in place of a removable cover
  • Same calibration, resin options and fitting layout as the open top tanks
  • LPE certified to NSF/ANSI/CAN 61 in all sizes; XLPE from 55 to 500 gallons
  • Also available in polypropylene and polyvinylidene fluoride (PVDF) on request

MATERIAL SELECTION GUIDANCE

Linear polyethylene (LPE) is typically selected for general chemical and water storage; cross-linked polyethylene (XLPE) where greater impact and stress-crack resistance is preferred; polypropylene (PP) and polyvinylidene fluoride (PVDF) for resin-specific chemistries. Choose based on chemical compatibility first: suitability depends on your specific chemical, its concentration and its temperature, and is the buyer's responsibility to verify before ordering. The specific gravity rating states the heaviest liquid the wall is designed to hold — a 1.5 wall up to about 12.5 lb per gallon, a 1.9 wall up to about 16 lb per gallon.

These are vented, atmospheric storage tanks. Not for pressurized or vacuum service.

CHEMICAL COMPATIBILITY RESOURCES

Compatibility data is published by resin and chemical suppliers as general guidance only. Contact us with your chemical, concentration and temperature before you order.

More details

KEY SPECIFICATIONS

  • Product Type: ProChem Solid Top Process Chemical Tank
  • Tank Shape: Cylindrical
  • Pressurized Use: No
  • Capacity: 30 Gallons
  • Dimensions: 18" diameter x 36.17" high
  • Material: Linear Polyethylene (LPE) 1.5 SG (01-30356)
  • Material: Linear Polyethylene (LPE) 1.9 SG (01-34627)
  • Material: Cross-Linked Polyethylene (XLPE) (01-30412)
  • Material: Polypropylene (PP) (01-30367)
  • Material: PVDF (01-30378)
  • Color: Natural
  • ANSI/NSF 61 Approved Resin: No
  • Manufacturer: Peabody Engineering
  • Manufacturer Part Number: 01-30356 / 01-34627 / 01-30412 / 01-30367 / 01-30378

SHIPPING INFORMATION

  • Freight Class: 250
  • Locations: Liberty, South Carolina
  • Zip Codes: 29657

WARRANTY TERMS

Peabody Engineering warrants this product against defects in material and workmanship for 36 months from the date of shipment, when it is installed, used and maintained as intended. Chemical compatibility, service temperature and liquid specific gravity are the buyer's responsibility: damage from an incompatible chemical, from service above the rated temperature, or from a liquid heavier than the wall rating is not covered.
