Product Description
60 Gallon Marine & RV Tank | Holding & Fresh Water | Trionic WH-2060-2
The 60 Gallon Trionic Marine & RV Tank (Holding & Fresh Water) | WH-2060-2 is designed for boats, RVs, and other mobile installations where a durable, space-efficient rectangular tank is required. This polyethylene tank supports potable/fresh water storage as well as wastewater holding (including grey and black water) in non-pressurized setups. With a footprint of 71" L × 18" W × 12" H, the WH-2060-2 provides high capacity while remaining straightforward to place in under-deck or compartmented layouts.
Trionic offers this tank in two configurations: a pre-drilled version with factory threaded openings, and a blank (no-opening) version for custom routing and fitting placement. The pre-drilled version includes (2) 1-1/2" FPT and (2) 1/2" FPT female NPT threaded openings located on one end (unused openings can be capped). The tank is rotationally molded as a seamless, one-piece unit with an approximate 3/8" average wall thickness. For blank-tank applications, the DIY CF-60 Custom Fittings Kit provides the components and instructions needed to add fittings where your installation requires them.
FEATURES
• Product Type: Marine & RV Tank (Holding & Fresh Water)
• Model: Trionic WH-2060-2
• Capacity: 60 Gallon
• Tank Shape: Rectangular
• Usability: Portable
• Environment: Above Ground
• Pressurized Use: No
• ANSI / NSF 61 Approved Resin: Yes
• Dimensions: 71" Length × 18" Width × 12" Height
• Material / Color: Polyethylene, Natural White
Other Details
KEY SPECIFICATIONS
- Product Type: Marine & RV Tank (Holding & Fresh Water)
- Model: Trionic WH-2060-2
- Capacity: 60 Gallon
- Tank Shape: Rectangular
- Usability: Portable
- Environment: Above Ground
- Pressurized Use: No
- Dimensions: 71" Length × 18" Width × 12" Height
- Material: Polyethylene
- Color: Natural White
- ANSI / NSF 61 Approved Resin: Yes
- Marine Reference: Meets U.S. Coast Guard regulations (as applicable)
- Configuration Options: Pre-drilled (threaded openings included) or Blank (no openings) for custom fitting placement
- Openings (Pre-drilled Version): (2) 1-1/2" FPT and (2) 1/2" FPT threaded openings (located on one end; unused openings can be capped)
- Thread Type: Female NPT (National Pipe Thread)
- Wall Thickness: 3/8" average
- Installation Note: Bottom should be fully supported; use a 12" minimum length of flexible hose to hose barb fittings
- Compatible Accessory: DIY CF-60 Custom Fittings Kit (for custom fitting placement/blank-tank applications)
- Warranty: 1-year (materials and workmanship)
COMPLIANCE REFERENCES
- NSF/ANSI 61 – Drinking Water System Components (Health Effects)
- FDA – 21 CFR § 177.1520 (Olefin Polymers; Polyethylene Resin Reference)
- USCG – 33 CFR Part 159 (Marine Sanitation Devices)
- NFPA 1192 – Standard on Recreational Vehicles
SHIPPING INFORMATION
- Freight Class: 300
- Liftgate Option: Yes
- Locations: Wisconsin
- Zip Codes: 53021
