Product Description
100 Gallon Marine & RV Tank | Holding & Fresh Water | Trionic WH-2100-2
The 100 Gallon Trionic Marine & RV Tank (Holding & Fresh Water) | WH-2100-2 is built for larger-capacity installations in boats, RVs, and other mobile applications where a durable, space-efficient tank is required. This rectangular polyethylene tank supports potable/fresh water storage as well as wastewater holding (including grey and black water) in non-pressurized setups. With a footprint of 49" L × 34" W × 15.25" H, the WH-2100-2 provides high capacity while maintaining flexible placement.
This model is offered in two configurations: a Pre-Drilled option with factory threaded ports, or a Blank option with no openings for custom routing and fitting placement. The Pre-Drilled tank includes (2) 1-1/2" FPT and (2) 1/2" FPT female NPT threaded openings located on one end (unused openings can be capped). The tank features an approximate 3/8" average wall thickness and should be installed with the bottom fully supported; Trionic also recommends using a minimum 12" flexible hose section to hose barb fittings for installation. If your application requires custom fitting placement (blank-tank configurations or custom routing), the DIY CF-60 Custom Fittings Kit provides common fitting components and installation guidance.
Features
-
Product Type: Marine & RV Tank (Holding & Fresh Water)
-
Model: Trionic WH-2100-2
-
Capacity: 100 Gallon
-
Tank Shape: Rectangular
-
Usability: Portable
-
Environment: Above Ground
-
Pressurized Use: No
-
ANSI / NSF 61 Approved Resin: Yes
-
Dimensions: 49" Length × 34" Width × 15.25" Height
-
Material / Color: Polyethylene, Natural White
-
Configuration Options: Pre-Drilled or Blank
Other Details
KEY SPECIFICATIONS
- Product Type: Marine & RV Tank (Holding & Fresh Water)
- Model: Trionic WH-2100-2
- Capacity: 100 Gallon
- Tank Shape: Rectangular
- Usability: Portable
- Environment: Above Ground
- Pressurized Use: No
- Dimensions: 49" Length × 34" Width × 15.25" Height
- Material: Polyethylene
- Color: Natural White
- ANSI / NSF 61 Approved Resin: Yes
- Marine Reference: Meets U.S. Coast Guard regulations (as applicable)
- Configuration Options: Pre-Drilled Tank or Blank Tank
- Openings (Pre-Drilled Option): (2) 1-1/2" FPT and (2) 1/2" FPT threaded openings (located on one end)
- Blank Option: No openings (for custom fitting placement)
- Thread Type: Female NPT (National Pipe Thread)
- Wall Thickness: 3/8" average
- Compatible Accessory: DIY CF-60 Custom Fittings Kit (for custom fitting placement/blank-tank applications)
- Warranty: 1-year (materials and workmanship)
COMPLIANCE REFERENCES
- NSF/ANSI 61 – Drinking Water System Components (Health Effects)
- FDA – 21 CFR § 177.1520 (Olefin Polymers; Polyethylene Resin Reference)
- USCG – 33 CFR Part 159 (Marine Sanitation Devices)
- NFPA 1192 – Standard on Recreational Vehicles
SHIPPING INFORMATION
- Freight Class: 250
- Liftgate Option: Yes
- Locations: Wisconsin
- Zip Codes: 53021
